Overview

The Threaded Y-Type Pneumatic Angle Seat Valve is one of the most widely used valves in industrial control systems, providing fast and precise control of steam, liquids, and gases. Its Y-pattern body design minimizes pressure loss while improving flow efficiency, and the BSP threaded connection ensures easy installation and maintenance, making it an ideal solution for a wide range of industrial applications.

⸻

Operating Principle

The valve is operated by a pneumatic actuator that moves the piston to open or close the flow path.

* Single Acting: The valve opens or closes using compressed air and returns to its default position by means of a spring when the air supply is removed.
* Double Acting: Both opening and closing are actuated by compressed air, providing faster response and more precise control in demanding industrial applications.

⸻

Technical Specifications

* Valve Type: Y-Type Pneumatic Angle Seat Valve
* Connection Type: BSP Threaded
* Valve Body Material: AISI 316 Stainless Steel
* Actuator Material: AISI 304 Stainless Steel
* Maximum Operating Temperature: Up to 180°C
* Operating Air Pressure: 3–8 bar
* Suitable Media: Air, water, steam, gases, and light oils
* Actuator Rotation: 360° rotatable actuator for easy installation

⸻

Features

* Fast and precise flow control.
* Y-pattern design minimizes pressure loss and improves flow efficiency.
* Excellent corrosion resistance with an AISI 316 stainless steel body.
* Suitable for high-temperature applications up to 180°C.
* Easy installation and maintenance with BSP threaded connections.
* 360° rotatable actuator for flexible mounting.
* Long service life with minimal maintenance requirements.
* Excellent sealing performance to minimize leakage.

⸻

Applications

The Threaded Pneumatic Angle Seat Valve is widely used in:

* Steam systems
* Water and industrial fluid pipelines
* Food and beverage processing
* Chemical processing plants
* Water and wastewater treatment systems
* CIP/SIP sterilization systems
* Textile dyeing equipment
* Industrial air and gas systems

⸻

Why Choose the Y-Type Pneumatic Angle Seat Valve?

The Y-Type Pneumatic Angle Seat Valve combines fast response, high reliability, and easy installation with outstanding performance in high-temperature and demanding industrial environments. Its optimized flow path enhances system efficiency, reduces energy loss, and provides a cost-effective, long-lasting solution for industrial flow control.
