A hot oil valve is a type of valve designed to control the flow of hot oil or other hot liquids. These valves are generally used in industrial or commercial environments where high temperatures and pressures are involved, such as process plants or power plants. The hot oil valve can be used in a variety of applications including
heating, cooling, lubrication and temperature control. In general, they are made of materials that are resistant to high temperatures and can withstand the corrosive effects of hot oils

General Features

• Product: 2 Way Pneumatic Proportional Control Valve For Hot Oil (with metal bellows addition)
• Dimensions: DN25 / DN32 / DN40 / DN50 / DN80 / DN100
• Usage Area: Pressurized Steam and Hot Oil Lines
• Connection Norm: Flange connection(DIN1092-2)
• Pressure Class: PN25
• Safety Position: Normally Closed – Normally Open
• Sealing Class: CLASS IV Metal to Metal
• Max. Operating temperature: 350 °C
• Neck Sealing: CLASS VI Package With Metal Bellows
• Characteristic: Equal Percent – Linear
