Description

The NAMUR Solenoid Valve is an essential component in industrial automation and control systems, designed to direct compressed air and actuate pneumatic actuators for automated valve control. This valve converts electrical signals into pneumatic operation, enabling fast and precise valve opening and closing.

Designed according to the NAMUR standard, the valve mounts directly onto the pneumatic actuator without the need for additional tubing or fittings. This reduces installation time, improves system efficiency, and minimizes the risk of air leakage.

—

Features

· Direct-mount design compliant with NAMUR standard
· Fast and precise response to electrical control signals
· Suitable for double-acting and single-acting pneumatic actuators
· Compact design for easy installation and maintenance
· Low power consumption
· Lubrication-free operation
· Reliable performance and long service life
· Designed for harsh industrial environments

—

Applications

The NAMUR Solenoid Valve is widely used in:

· Automated valve control systems
· Pneumatic actuators for ball valves and butterfly valves
· Chemical and petrochemical industries
· Food and beverage industry
· Pharmaceutical industries
· Water treatment plants
· Power generation plants
· Compressed air systems
· SCADA and PLC automation systems
· Heating, ventilation, and air conditioning (HVAC) systems

—

Technical Specifications

· Model: SV210
· Valve Type: NAMUR 5/2-way solenoid valve
· Material: Aluminum
· Operating Medium: Clean, dry, filtered compressed air
· Port Size: PF 1/4 inch
· Maximum Operating Pressure: 12 bar
· Operating Temperature: -5°C to +70°C
· Orifice Size: 14 mm²
· Power Consumption:
· AC: 2.0–3.5 VA
· DC: 2.5 W
· Maximum Operating Frequency: 5 cycles/second
· Protection Class: IP65
· Lubrication: Not required

—

Performance Advantages

The NAMUR Solenoid Valve provides fast response and precise control over pneumatic actuators, improving the efficiency of industrial automation systems and reducing response time. Its direct NAMUR-mount design reduces the number of connections, limits the potential for air leakage, simplifies installation and maintenance, and enhances overall energy efficiency.

—

Installation and Maintenance

The valve is designed for direct mounting onto pneumatic actuators in accordance with the NAMUR standard, ensuring quick and secure installation. For optimal performance, it is recommended to use clean, dry, filtered compressed air and to perform periodic inspections of electrical connections, the solenoid coil, and sealing components to ensure long-term reliable operation.

—

Why Choose UNOX NAMUR Solenoid Valves?

UNOX NAMUR Solenoid Valves are manufactured to the highest international quality standards, ensuring reliable performance and fast response across a wide range of industrial automation applications. Their ease of installation, low power consumption, and compatibility with most standard pneumatic actuators make them the ideal solution for industrial valve automation and process control.
